Gasoline Generator

• Specification Code:BS2800R

Output Power: 2.5kw～2.8kw; Voltage&Frequency: 220V/50Hz; Engine Type: BS170F; Alternator: Copper Wire 160*100MM; Start System: Recoil Start; Other Option: Without Wheel

portable power gasoline generator
Engine	Engine Model	BS168F
	Engine Output	5.5HP
	Bore x stroke	68 x 45mm
	Displacement	163cc
	Compression ratio	8.5:1
	Rated rotation speed	3000 / 3600rpm
	Oil capacity	3.6L
Generator	Rated frequency	50/60HZ
	Rated voltage	110/220/380v
	Rated output power	2.0kw
	Max output power	2.2kw
	Alternator	Aluminum / Copper
	Power factor	1 cosθ
	Socket	5 x 220v
	Phase	1/3 phase
	Structure type	Open frame type
	Starting system	Recoil start / Electric start
	Fuel tank capacity	15L
	Net/Gross weight	41.5kg
	Overall dimension	605 x 470x 435mm
	20FT	235set
	40HQ	593set
